Turnouts

This section on turnouts may sound boring, but I found it simple, to the point, and easy to understand.

The following is from the C. Frank Allen book RAILROAD CURVES and
EARTHWORK, published in 1931 by McGraw-Hill. Page 79.

A turnout is a track leading from a main or other track.

Turnouts may be for several purposes.

1. Branch Track (for line used as a Branch Road for general traffic).
2. Siding (for passing trains at stations, storing cars, loading or unloading, and
   various purposes).
3. Spur Track (for purposes other than general traffic, as to a quarry or
   warehouse).
4. Crossover For passing from one track to another, generally parallel).

The essential parts of a turnout are: 1. The Switch, 2. The Frog, 3. The Guard Rail.

1. Some device is necessary to cause a train to turn from the main track; this is called
the "Switch."
2. Again, it is necessary that one rail of the turnout track should cross one rail of the
main track; and some device is necessary to allow the flange of the wheel to pass this
crossing; this device is called the "Frog."
3. Finally, if the flange of the wheel were allowed to bear against the point of the frog,
there is a danger that the wheel might accidentally be turned to the wrong side of the
frog point. Therefore a Guard Rail is set opposite to the frog, and this prevents the
flange from bearing against the frog point.
